Welcome to ADSInfo.com, your fabricator for prototype/custom coils, inductors and transformers.   We assist engineers, designers, and inventors to solve their specialty magnetic component needs, even if only one coil is needed or a 100.

We primarily serve the electrical and electronics industries. However, we will gladly assist in the restoration/repair of coils for vintage and antique electronics, arcade equipment and in other industries.

ADSInfo.com has been providing technical solutions since 1986. All of the products we custom manufacture are assembled and tested in Colorado, USA.

How can we assist you?

Email: indctrl@adsinfo.com or call: 1-303-841-0268





Practically any number of sectors, wiring configurations and core sizes are possible. Pictured: laminated toroid core with one continuous coil winding, forming 4 quadrants/sectors, ready for potting.

  Toroidal Coil Winding Custom/Prototype Services
  • Maximum Coil O.D.: 15.0" (38.1cm)
  • Minimum Coil O.D.: 0.218" (5.5mm)
  • Minimum Coil I.D.: 0.055" (1.4mm)
  • Maximum Coil Height: 4.00" (10.16cm)
  • Wire Sizes: #4 - #58 AWG *
  • Square, rectangle, round or Litz wire
  • Maximum 5 multifilar windings
  • Irregular shapes, larger/smaller coils and custom windings quoted
  • Multiple section/phases


Bobbin size, windings, and shape limited only by your imagination. Pictured: Custom fabricated prototype 3-axis bobbin wound with 3 separate coils.

  Bobbin Coil Winding Custom/Prototype Services
  • Maximum Length: 20" (50.8cm)
  • Maximum Diameter: 32" (81.28cm)
  • Wire Sizes: #4 - #58 AWG *
  • Square, rectangle, round or Litz wire
  • Maximum 5 multifilar windings
  • Irregular shapes, larger/smaller coils and custom windings quoted
  • Custom coil forms and bobbins quoted and manufactured
  • Coils, Inductors, Transformers


Custom shapes and tooling made to order. Pictured: Self-supported coil, outside diameter 4", inside diameter 3.1", height 0.9".



  Self-Supporting Coil Winding Custom/Prototype Services

  • Maximum Length: 20" (50.8cm)
  • Maximum Diameter: 32" (81.28cm)
  • Wire Sizes: #4 - #58 AWG *
  • Square, rectangle, round or Litz wire
  • Maximum 5 multifilar windings
  • Irregular shapes, larger/smaller coils and custom windings quoted
  • Numerous bonding methods & materials available



Prototype winding services services are rendered based on flat hourly fee plus materials.  Custom setup/fixture charges, minimum wire purchase for non-stock wire, are additional when they apply.  Call 1-303-841-0268 (USA) or email indctrl@adsinfo.com for details.

* Note: Not all wire sizes and types are available for all sizes of bobbins, toroids and self-supporting coils.

Thank you for considering ADS!
